Water tank truck structure and classification

Water tank trucks are special vehicles that are used to transport water. Tank vehicles are widely used in sanitation, oil transportation, and chemical product transportation.

Water tank trucks are divided into automobile type, semi-trailer type and trailer type sprinkler according to the chassis; how many square meters or tons of sprinklers can be divided according to the capacity; according to the different chassis, it can be divided into Dongfeng, Jiefang, Futian, Jianghuai, etc .

Optional Water Tank Truck

The prices of water tank trucks produced by various production plants in different regions are different.

Standard configuration (greening spray truck, water tanker truck): front flush, rear spray, side spray; high side shower; rear working platform with green sprinkler, can be adjusted into a column shape with a range of ≥28m; it can also be adjusted into a mist shape, The range is ≥15m. Optional medicine plate, fight drugs machine. It can also be equipped with advanced facilities such as medicine trays, medicine tray pumps, anti-corrosion and anti-rust inside the tank, multi-directional water inlet and outlet joints, solenoid valves, and pneumatic valves to meet the needs of different users.

1. Water tank truck tank production, using automatic assembly line tank production process is divided into: cutting, automatic welding of the panel, head spinning and forming, one-time roll forming of the tank and other domestic advanced production processes. Tank materials are mostly produced using high-quality carbon steel plates. For special applications, 304 stainless steel can also be used according to customer needs. Tank volume is "4 cubic, 5 cubic, 6 cubic, 8 cubic, 10 cubic, 13 cubic, 15 cubic" and so on. The piping system consists of pipes, four-position three-way ball valves, straight-through ball valves, filters, water outlets, front flush, side spray, and high side showers.

2. The working platform behind the water tanker is composed of green sprinkler anti-aircraft guns. The operating system is mainly driven by the engine. The power take-off installed on the gearbox drives the sprinkler pump. The sprinkler pump generates power and sprays the liquid inside the tank through the pipe network. Working range: self-priming height: ≥7m, watering width: ≥14m, maximum range: ≥28m; can be adjusted into a column shape, the range is ≥28m; it can also be adjusted into a mist shape, the range is ≥5m. Sprinkler pump, equipped with sprinkler, green sprayer, high-power special sprinkler pump (weilong pump), with fire connector, with self-flow valve, with self-priming function.

3. Water tank trucks can be equipped with optional equipment: it can be equipped with advanced facilities such as medicine trays, pumps, anti-corrosion and anti-rust inside the tank, multi-directional water inlet and outlet joints, solenoid valves, and pneumatic valves to meet the needs of different users. Cab, sprinkler cab is divided into: pointed cab, or flat-head cab, also known as long-head cab, short-head cab. Power take-off, the general sprinkler uses Dongfeng, Jiefang series power take-off, pneumatic operation, the operation switch is pulled backward, the power take-off tooth enters the bite position, the water pump is driven by the drive shaft, the switch returns to the position, the water pump stops working.
